SKF
2204ETN9/C3 - SKF Double Row Self-Aligning Bearing - 20x47x18
SKU: 2204etn9/c3-skf
Availability: In Stock ✅
BULK PRICING: Click Here to Enquire
Description
This 2204ETN9/C3 bearing is a double row, wide series, metric self aligning bearing with an optimized internal design for increased load carrying capacity, a glass fibre reinforced PA66 cage and a larger than normal radial internal clearance. The bearing's dimensions are 20x47x18.
| 22 | 04 | e | tn9 | c3 | |
|---|---|---|---|---|---|
| Wide | Bore Size - 20mm | Extra Capacity | Glass Fibre Reinforced PA66 Cage, Ball Centred | Radial Internal Clearance Greater than Normal |
Product Information
Technical Data
Inside Diameter (mm):
20mm
Outside Diameter (mm):
47mm
Width (mm):
18mm
Cage Type:
Plastic
Seals Or Shields:
Open Type
Clearance:
C3
Dynamic Load Rating (kN):
16.8
Static Load Rating (kN):
4.15
Fatigue Load Rating (kN):
0.22
Reference Speed Rating (r/min):
28000
Limiting Speed Rating (r/min):
20000
DescriptionThis 2204ETN9/C3 bearing is a double row, wide series, metric self aligning bearing with an optimized internal design for increased load carrying capacity, a glass fibre reinforced PA66 cage and a larger than normal radial internal clearance. The bearing's dimensions are 20x47x18.
Product InformationBRAND: SKU:2204etn9/c3-skf AVAILABILITY:In Stock ✅ WEIGHT:0.14 kg Technical DataInside Diameter (mm):20mm Outside Diameter (mm):47mm Width (mm):18mm Cage Type:Plastic Seals Or Shields:Open Type Clearance:C3 Dynamic Load Rating (kN):16.8 Static Load Rating (kN):4.15 Fatigue Load Rating (kN):0.22 Reference Speed Rating (r/min):28000 Limiting Speed Rating (r/min):20000 | ||||||||||||
