FAG
3317-M-C3 - FAG Double Row Angular Contact - 85x180x73mm
SKU: 3317-m-c3-fag
Availability: In Stock ✅
BULK PRICING: Click Here to Enquire
Description
This 3317-M-C3 bearing is a metric double row angular contact bearing with a brass cage and a larger than standard radial internal clearance. The bearing's dimensions are 85x180x73mm.
| 33 | 17 | M | C3 | ||
|---|---|---|---|---|---|
| Maximum Capacity, Medium Series | 85mm - Bore Size | Open Type | Solid Brass Cage, Ball Guided | Axial Internal Clearance Greater than Normal |
Product Information
Technical Data
Inside Diameter (mm):
85mm
Outside Diameter (mm):
180mm
Width (mm):
73mm
Cage Type:
Brass
Seals Or Shields:
Open Type
Clearance:
C3
Dynamic Load Rating (kN):
190
Static Load Rating (kN):
228
Fatigue Load Rating (kN):
11.1
Reference Speed Rating (r/min):
3750
Limiting Speed Rating (r/min):
3400
DescriptionThis 3317-M-C3 bearing is a metric double row angular contact bearing with a brass cage and a larger than standard radial internal clearance. The bearing's dimensions are 85x180x73mm.
Product InformationBRAND: SKU:3317-m-c3-fag AVAILABILITY:In Stock ✅ WEIGHT:8.78 kg Technical DataInside Diameter (mm):85mm Outside Diameter (mm):180mm Width (mm):73mm Cage Type:Brass Seals Or Shields:Open Type Clearance:C3 Dynamic Load Rating (kN):190 Static Load Rating (kN):228 Fatigue Load Rating (kN):11.1 Reference Speed Rating (r/min):3750 Limiting Speed Rating (r/min):3400 | ||||||||||||
