51332M - SKF Single Direction Thrust Bearing - 160x270x87mm

Name: 51332M - SKF Single Direction Thrust Bearing - 160x270x87mm
Brand: SKF
SKU: 51332m-skf
Availability: InStock

SKU: 51332m-skf

Availability: In Stock ✅

BULK PRICING: Click Here to Enquire

C$6,327.70

51332M - SKF Single Direction Thrust Bearing - 160x270x87mm

Description

This 51332M bearing is a Single direction thrust bearing with a flat housing locating washer and a machined brass cage, ball centred. The bearing's dimensions are 160x270x87.

513	32	M
Single Direction Thrust Bearing	Bore Size - 160mm	Machined Brass Cage, Ball Centred

Product Information

BRAND:

SKU:51332m-skf

AVAILABILITY:In Stock ✅

WEIGHT:21 kg

Technical Data

Inside Diameter (mm):

160mm

Outside Diameter (mm):

270mm

Width (mm):

87mm

Cage Type:

Brass

Seals Or Shields:

Open Type

Clearance:

Standard

Dynamic Load Rating (kN):

449

Static Load Rating (kN):

1660

Fatigue Load Rating (kN):

41.5

Reference Speed Rating (r/min):

850

Limiting Speed Rating (r/min):

1200

Description

This 51332M bearing is a Single direction thrust bearing with a flat housing locating washer and a machined brass cage, ball centred. The bearing's dimensions are 160x270x87.

513	32	M
Single Direction Thrust Bearing	Bore Size - 160mm	Machined Brass Cage, Ball Centred

Product Information

BRAND:

SKU:51332m-skf

AVAILABILITY:In Stock ✅

WEIGHT:21 kg

Technical Data

Inside Diameter (mm):

160mm

Outside Diameter (mm):

270mm

Width (mm):

87mm

Cage Type:

Brass

Seals Or Shields:

Open Type

Clearance:

Standard

Dynamic Load Rating (kN):

449

Static Load Rating (kN):

1660

Fatigue Load Rating (kN):

41.5

Reference Speed Rating (r/min):

850

Limiting Speed Rating (r/min):

1200
