Description
The SKF 6314 C3 is a deep groove ball bearing with a larger than standard radial internal clearance designed for high-speed, high-load applications. It features a 70mm bore, 150mm outside diameter, and 35mm width. With C3 internal clearance and an open design, it’s suitable for environments where increased thermal expansion or shaft misalignment may occur.
| 63 | 14 | C3 | |
|---|---|---|---|
| Medium Series | 70mm - Bore Size | Open Type | Radial Internal Clearance Greater Than Normal |
Key Features
C3 Internal Clearance
The 6314 C3 bearing has greater-than-standard radial clearance. It allows for thermal expansion and is ideal for higher-speed or higher-temperature settings.
Load Ratings
With a dynamic load rating of 111 kN and a static load rating of 68 kN, the 6314 C3 handles both radial and axial loads. Its fatigue load rating is 2.75 kN, making it reliable for long-term use under moderate load.
Open Type Design
Due to the open type design the 6314 C3 is best suited to applications where contamination is controlled and frequent lubrication is possible.
Versatile Applications
The 6314 C3 SKF bearing is used across a wide range of industries. It would be suitable for electric motors, pumps, gearboxes, fans, and general machinery.
Product Information
Technical Data
Inside Diameter (mm) :
70mm
Outside Diameter (mm) :
150mm
Width (mm) :
35mm
Cage Type :
Steel
Seals Or Shields :
Open Type
Clearance :
C3
Dynamic Load Rating (kN) :
111
Static Load Rating (kN) :
68
Fatigue Load Rating (kN) :
2.75
Reference Speed Rating (r/min) :
9500
Limiting Speed Rating (r/min) :
6300
DescriptionThe SKF 6314 C3 is a deep groove ball bearing with a larger than standard radial internal clearance designed for high-speed, high-load applications. It features a 70mm bore, 150mm outside diameter, and 35mm width. With C3 internal clearance and an open design, it’s suitable for environments where increased thermal expansion or shaft misalignment may occur.
Key FeaturesC3 Internal ClearanceThe 6314 C3 bearing has greater-than-standard radial clearance. It allows for thermal expansion and is ideal for higher-speed or higher-temperature settings. Load RatingsWith a dynamic load rating of 111 kN and a static load rating of 68 kN, the 6314 C3 handles both radial and axial loads. Its fatigue load rating is 2.75 kN, making it reliable for long-term use under moderate load. Open Type DesignDue to the open type design the 6314 C3 is best suited to applications where contamination is controlled and frequent lubrication is possible. Versatile ApplicationsThe 6314 C3 SKF bearing is used across a wide range of industries. It would be suitable for electric motors, pumps, gearboxes, fans, and general machinery. Product InformationBRAND: SKU:6314/c3-skf AVAILABILITY:In Stock ✅ WEIGHT:2.55 kg Technical DataInside Diameter (mm) :70mm Outside Diameter (mm) :150mm Width (mm) :35mm Cage Type :Steel Seals Or Shields :Open Type Clearance :C3 Dynamic Load Rating (kN) :111 Static Load Rating (kN) :68 Fatigue Load Rating (kN) :2.75 Reference Speed Rating (r/min) :9500 Limiting Speed Rating (r/min) :6300 | ||||||||
