SKF
6332M/C3VL2071 - SKF Deep Groove Radial Ball Bearings - 160x340x68mm
SKU: 6332m/c3vl2071-skf
Availability: In Stock ✅
BULK PRICING: Click Here to Enquire
Description
The SKF 6332M C3 VL2071 is a high-quality insulated bearing machined with a brass cage, designed for demanding industrial applications. Featuring SKF’s advanced INSOCOAT technology, the 6332M bearing offers superior electrical insulation, preventing damage from stray electric currents in motor and generator applications. With its C3 clearance, it ensures smooth operation even in harsh conditions. The bearing dimensions are 160x340x68mm.
| 63 | 32 | m | c3 | vl2071 | |
|---|---|---|---|---|---|
| Metric, Medium Series | 160mm - Bore Size | Open Type | Brass Cage | Internal Clearance Greater Than Normal | External surfaces of the inner ring have an INSOCOAT |
Key Features
INSOCOAT Insulation
The SKF 6332M C3 VL2071 bearing comes coated with an aluminium oxide layer (VL2071). This provides an advanced electrical resistance, protecting against both electrical erosion and premature failure.
C3 Clearance
Designed for applications requiring higher-than-normal running temperatures or speeds, the 6332MC3VL2071 bearing has been manufactured to ensure reduced friction and extended lifespan.
High-Quality Materials
Manufactured from premium-grade steel for enhanced durability and performance. The 6332M bearing has a reduced need for lubrication, making it ideal for long-term industrial use.
Product Information
Technical Data
Inside Diameter (mm):
160mm
Outside Diameter (mm):
340mm
Width (mm):
68mm
Cage Type:
Brass
Seals Or Shields:
Open Type
Clearance:
C3
Dynamic Load Rating (kN):
276
Static Load Rating (kN):
285
Fatigue Load Rating (kN):
7.8
Reference Speed Rating (r/min):
4000
Limiting Speed Rating (r/min):
4300
DescriptionThe SKF 6332M C3 VL2071 is a high-quality insulated bearing machined with a brass cage, designed for demanding industrial applications. Featuring SKF’s advanced INSOCOAT technology, the 6332M bearing offers superior electrical insulation, preventing damage from stray electric currents in motor and generator applications. With its C3 clearance, it ensures smooth operation even in harsh conditions. The bearing dimensions are 160x340x68mm.
Key FeaturesINSOCOAT InsulationThe SKF 6332M C3 VL2071 bearing comes coated with an aluminium oxide layer (VL2071). This provides an advanced electrical resistance, protecting against both electrical erosion and premature failure. C3 ClearanceDesigned for applications requiring higher-than-normal running temperatures or speeds, the 6332MC3VL2071 bearing has been manufactured to ensure reduced friction and extended lifespan. High-Quality MaterialsManufactured from premium-grade steel for enhanced durability and performance. The 6332M bearing has a reduced need for lubrication, making it ideal for long-term industrial use. Product InformationBRAND: SKU:6332m/c3vl2071-skf AVAILABILITY:In Stock ✅ WEIGHT:30.32 kg Technical DataInside Diameter (mm):160mm Outside Diameter (mm):340mm Width (mm):68mm Cage Type:Brass Seals Or Shields:Open Type Clearance:C3 Dynamic Load Rating (kN):276 Static Load Rating (kN):285 Fatigue Load Rating (kN):7.8 Reference Speed Rating (r/min):4000 Limiting Speed Rating (r/min):4300 | ||||||||||||
