7013CTRDUDMP3 - NSK Precision Angular Contact - 65x100x18mm

Name: 7013CTRDUDMP3 - NSK Precision Angular Contact - 65x100x18mm
Brand: NSK
SKU: 7013ctrdudmp3-nsk
Availability: InStock

SKU: 7013ctrdudmp3-nsk

Availability: In Stock ✅

BULK PRICING: Click Here to Enquire

C$1,355.39

7013CTRDUDMP3 - NSK Precision Angular Contact - 65x100x18mm

Description

This 7013CTRDUDMP3 bearing is a Super Precision angular contact bearing with a 15° contact angle and a phenolic cage, this bearing is a universal fit triple set of bearings with a medium preload and a P3 precision rating. The bearing's dimensions are 65x100x18.

70	13	CTR	DUD	M	P3
Extra Light Series	65mm - Bore Size	15° Contact Angle	Triplex Universal	Medium Preload	Precision Rating

Product Information

BRAND:

SKU:7013ctrdudmp3-nsk

AVAILABILITY:In Stock ✅

WEIGHT:0.435 kg

Technical Data

Inside Diameter (mm):

65mm

Outside Diameter (mm):

100mm

Width (mm):

18mm

Cage Type:

Plastic

Seals Or Shields:

Open Type

Clearance:

Standard

Dynamic Load Rating (kN):

Static Load Rating (kN):

34.5

Grease Limiting Speed (r/min):

14000

Oil Limiting Speed (r/min):

21300

Preload:

Medium

Description

70	13	CTR	DUD	M	P3
Extra Light Series	65mm - Bore Size	15° Contact Angle	Triplex Universal	Medium Preload	Precision Rating

Product Information

BRAND:

SKU:7013ctrdudmp3-nsk

AVAILABILITY:In Stock ✅

WEIGHT:0.435 kg

Technical Data

Inside Diameter (mm):

65mm

Outside Diameter (mm):

100mm

Width (mm):

18mm

Cage Type:

Plastic

Seals Or Shields:

Open Type

Clearance:

Standard

Dynamic Load Rating (kN):

Static Load Rating (kN):

34.5

Grease Limiting Speed (r/min):

14000

Oil Limiting Speed (r/min):

21300

Preload:

Medium
