NSK
7036CTRDUMP3 - NSK Precision Angular Contact - 180x280x46mm
SKU: 7036ctrdump3-nsk
Availability: In Stock ✅
BULK PRICING: Click Here to Enquire
Description
This 7036CTRDUMP3 bearing is a Super Precision angular contact bearing with a 15° contact angle and a phenolic cage, this bearing is a universal fit double set of bearings with a medium preload and a P3 precision rating. The bearing's dimensions are 180x280x46.
| 70 | 36 | CTR | DU | M | P3 |
|---|---|---|---|---|---|
| Series - Extra Light | Bore Size - 180mm | 15 Degree Contact Angle | Duplex Universal | Medium Preload | Precision Rating |
Product Information
Technical Data
Inside Diameter (mm):
180mm
Outside Diameter (mm):
280mm
Width (mm):
46mm
Cage Type:
Plastic
Seals Or Shields:
Open Type
Clearance:
Standard
Dynamic Load Rating (kN):
228
Static Load Rating (kN):
276
Grease Limiting Speed (r/min):
5000
Oil Limiting Speed (r/min):
7700
Preload:
Medium
DescriptionThis 7036CTRDUMP3 bearing is a Super Precision angular contact bearing with a 15° contact angle and a phenolic cage, this bearing is a universal fit double set of bearings with a medium preload and a P3 precision rating. The bearing's dimensions are 180x280x46.
Product InformationBRAND: SKU:7036ctrdump3-nsk AVAILABILITY:In Stock ✅ WEIGHT:10.4 kg Technical DataInside Diameter (mm):180mm Outside Diameter (mm):280mm Width (mm):46mm Cage Type:Plastic Seals Or Shields:Open Type Clearance:Standard Dynamic Load Rating (kN):228 Static Load Rating (kN):276 Grease Limiting Speed (r/min):5000 Oil Limiting Speed (r/min):7700 Preload:Medium | ||||||||||||
