SKF
SKU: bsa209cga-skf
Availability: In Stock ✅
BULK PRICING: Click Here to Enquire
Engineered by SKF, the BSA209CGA Super Precision Angular Contact Thrust is a premium-quality bearing designed specifically for high-performance screw drives. SKF is an industry leader in bearing production, and with this bearing they have combined advanced technology with robust materials to ensure exceptional durability, precision, and efficiency in demanding applications. These bearings have a 62° contact angle and accommodate axial loads in one direction only, meaning they are adjusted against a second bearing or fitted as a set. The dimensions of this BSA209 CGA bearing are 45x85x19mm.
| BSA2 | 09 | C | GA |
|---|---|---|---|
| Single Direction Bearing - ISO Dimension Series 02 | 45mm - Bore Size | Improved Internal Design | Universally Matchable, Light Preload |
Designed to withstand heavy radial loads and heavy axial loads in one direction, the BSA209CGA Angular Contact Thrust Bearing is purposely manufactured to provide reliable performance in heavy-duty applications, including incidental overloading, better than other more conventional designs.
Manufactured with high precision to ensure smooth operation, the BSA209 CGA Angular Contact Thrust Bearing helps to reduce friction and wear, ultimately contributing to an extended lifespan.
This Angular Contact Thrust Bearing offers excellent stability and support for axial loads, enhancing the performance and accuracy of screw drivers. It is ideal for use in a variety of screw drives.
45mm
85mm
19mm
Standard
Open Type
Plastic
45
4.9
6300
7500
Light
134
62
DescriptionEngineered by SKF, the BSA209CGA Super Precision Angular Contact Thrust is a premium-quality bearing designed specifically for high-performance screw drives. SKF is an industry leader in bearing production, and with this bearing they have combined advanced technology with robust materials to ensure exceptional durability, precision, and efficiency in demanding applications. These bearings have a 62° contact angle and accommodate axial loads in one direction only, meaning they are adjusted against a second bearing or fitted as a set. The dimensions of this BSA209 CGA bearing are 45x85x19mm.
Key FeaturesHigh Load CapacityDesigned to withstand heavy radial loads and heavy axial loads in one direction, the BSA209CGA Angular Contact Thrust Bearing is purposely manufactured to provide reliable performance in heavy-duty applications, including incidental overloading, better than other more conventional designs. Precision EngineeringManufactured with high precision to ensure smooth operation, the BSA209 CGA Angular Contact Thrust Bearing helps to reduce friction and wear, ultimately contributing to an extended lifespan. Angular Contact DesignThis Angular Contact Thrust Bearing offers excellent stability and support for axial loads, enhancing the performance and accuracy of screw drivers. It is ideal for use in a variety of screw drives. Product InformationBRAND: SKU:bsa209cga-skf AVAILABILITY:In Stock ✅ WEIGHT:0.44 kg Technical DataInside Diameter (mm):45mm Outside Diameter (mm):85mm Width (mm):19mm Clearance:Standard Seals Or Shields:Open Type Cage Type:Plastic Dynamic Load Rating (kN):45 Fatigue Load Rating (kN):4.9 Grease Limiting Speed (r/min):6300 Oil Limiting Speed (r/min):7500 Preload:Light Static Load Rating (kN):134 Contact Angle:62 | ||||||||
Bulk PricingFor bulk discount on this product, contact our dedicated sales team today by filling out the form below: | ||||||||
