SKF
SKU: btw95ctn9/sp-skf
Availability: In Stock ✅
BULK PRICING: Click Here to Enquire
Enhance the performance of your machinery with the SKF BTW95CTN9/SP Super Precision Angular Contact Thrust Ball Bearing. Specifically engineered for high-speed applications, these bearings provide exceptional accuracy and stability and are designed to axially locate the shafts of spindles in both directions. BTW95 CTN9/SP bearings offer a high-speed design and are intended for mounting in combination with NN30 K or N10 K Cylindrical Roller Bearings. The dimensions of this BTW95CTN9/SP bearing are 95x145x60mm.
| BTW | 95 | C | TN9 | /SP |
|---|---|---|---|---|
| Basic Design Double Direction Angular Contact Thrust Bearing | 95mm - Bore Size | 60° Contact Angle | Two Glass Fibre Reinforced PA66 Cages, Snap-Type, Ball Centered | ISO Tolerance Class 5 Dimensional Accuracy, Class 4 Running Accuracy |
Manufactured with tight tolerances, the Super Precision BTW95 CTN9/SP bearing is manufactured by SKF to ensure a consistently high rotational accuracy and optimal performance.
Capable of handling axial loads in both directions, the BTW95CTN9/SP Super Precision Angular Contact Thrust Bearing has a double direction design which provides enhanced versatility and reliability in machinery.
The BTW95 CTN9/SP bearing is made up of two separable Single Row Angular Contact Thrust Ball Bearings with a 60° contact angle in a back-to-back arrangement. Configured in this way, and with the large number of balls the bearings contain, means these bearings can accommodate heavy axial loads in both directions while providing a high degree of system rigidity.
95mm
145mm
60mm
Plastic
Open Type
Standard
57.2
180
7.8
5000
6000
No Preload
60
DescriptionEnhance the performance of your machinery with the SKF BTW95CTN9/SP Super Precision Angular Contact Thrust Ball Bearing. Specifically engineered for high-speed applications, these bearings provide exceptional accuracy and stability and are designed to axially locate the shafts of spindles in both directions. BTW95 CTN9/SP bearings offer a high-speed design and are intended for mounting in combination with NN30 K or N10 K Cylindrical Roller Bearings. The dimensions of this BTW95CTN9/SP bearing are 95x145x60mm.
Key FeaturesHigh PrecisionManufactured with tight tolerances, the Super Precision BTW95 CTN9/SP bearing is manufactured by SKF to ensure a consistently high rotational accuracy and optimal performance. Double Directional LoadsCapable of handling axial loads in both directions, the BTW95CTN9/SP Super Precision Angular Contact Thrust Bearing has a double direction design which provides enhanced versatility and reliability in machinery. Angular Contact DesignThe BTW95 CTN9/SP bearing is made up of two separable Single Row Angular Contact Thrust Ball Bearings with a 60° contact angle in a back-to-back arrangement. Configured in this way, and with the large number of balls the bearings contain, means these bearings can accommodate heavy axial loads in both directions while providing a high degree of system rigidity. Product InformationBRAND: SKU:btw95ctn9/sp-skf AVAILABILITY:In Stock ✅ WEIGHT:2.8 kg Technical DataInside Diameter (mm):95mm Outside Diameter (mm):145mm Width (mm):60mm Cage Type:Plastic Seals Or Shields:Open Type Clearance:Standard Dynamic Load Rating (kN):57.2 Static Load Rating (kN):180 Fatigue Load Rating (kN):7.8 Grease Limiting Speed (r/min):5000 Oil Limiting Speed (r/min):6000 Preload:No Preload Contact Angle:60 | ||||||||||
