Engineered to the highest standards, the N1010KPHA/SP bearing is part of the SKF N10 series of Single Row Super Precision Cylindrical Roller Bearings, specifically engineered to meet the demanding needs of high-speed industrial applications. This bearing has a carbon fibre reinforced PEEK cage and no flanges on the outer ring, making the inner race and roller and cage assembly separable from the outer ring. It also allows the bearing to accommodate axial displacement of the shaft relative to the housing in both directions. Whether you operate in the aerospace, robotics, or precision machinery industry, the N1010 KPHA/SP is your go-to solution for ensuring optimal functionality and longevity. The dimensions of this N1010KPHA/SP bearing are 50x80x16mm.

Key Features

Superior Precision

The bearing boasts dimensional accuracy at ISO tolerance class 5 and running accuracy at ISO tolerance class 4. Manufactured with these tight tolerances, the N1010 KPHA/SP bearing by SKF ensures exceptional accuracy and minimal operational deviation even in difficult operating conditions.

High-Speed Capability

The N1010KPHA/SP super precision bearing is designed to perform at high speeds without compromising stability. This makes it ideal for applications that demand rapid rotation.

Optimised Load Distribution and Carrying

The cylindrical roller design of the N1010 KPHA/SP bearing ensures even load distribution and carries heavy radial loads while maintaining a low cross-sectional height and low friction. This helps to enhance performance and ultimately extend the bearing’s lifespan.
