Description
This N1010KTNHA/SP bearing is a single row super precision cylindrical roller bearing with a double ribbed inner ring, a glass fibre reinforced PEEK cage, a 1:12 tapered bore and a P5 accuracy class.. The bearing's dimensions are 50x80x16.
| N | 10 | 10 | K | TNHA | SP | |
|---|---|---|---|---|---|---|
| Single Row Cylindrical Roller | Bearing In Accordance with ISA Dimension Series 10 | 50mm - Bore Size | Tapered Bore, Taper 1:12 | Glass Fibre Reinforced PEEK Cage, Outer Ring Centred | Carbon Chromium Steel | Precision Rating |
Product Information
Technical Data
Inside Diameter (mm) :
50mm
Outside Diameter (mm) :
80mm
Width (mm) :
16mm
Cage Type :
Plastic
Seals Or Shields :
Open Type
Clearance :
Standard
Dynamic Load Rating (kN) :
29.7
Static Load Rating (kN) :
34.5
Fatigue Load Rating (kN) :
4.05
Grease Limiting Speed (r/min) :
19000
Oil Limiting Speed (r/min) :
26000
DescriptionThis N1010KTNHA/SP bearing is a single row super precision cylindrical roller bearing with a double ribbed inner ring, a glass fibre reinforced PEEK cage, a 1:12 tapered bore and a P5 accuracy class.. The bearing's dimensions are 50x80x16.
Product InformationBRAND: SKU:n1010ktnha/sp-skf AVAILABILITY:In Stock ✅ WEIGHT:0.26 kg Technical DataInside Diameter (mm) :50mm Outside Diameter (mm) :80mm Width (mm) :16mm Cage Type :Plastic Seals Or Shields :Open Type Clearance :Standard Dynamic Load Rating (kN) :29.7 Static Load Rating (kN) :34.5 Fatigue Load Rating (kN) :4.05 Grease Limiting Speed (r/min) :19000 Oil Limiting Speed (r/min) :26000 | ||||||||||||||
