Description
The NA4832 is a Standard Duty Open Type, Single Row Machined Needle Roller Bearing with an Inner Ring. The Inner Ring is separable from the Cage and Outer Ring, while the Outer Ring is fixed to the Cage and has an oil groove and an oil hole. Bearings with an Inner Ring are used when the shaft being used isn't heat-treated and finished by grinding. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 160X200X40mm.
The INA equivalent is NA4832-XL.
| NA | 48 | 32 | |
|---|---|---|---|
| Single Row Caged Needle Roller Bearing | Dimension Series 48 | 160mm - Bore Size | Including Inner Ring |
Product Information
Technical Data
Inside Diameter (mm):
160
Outside Diameter (mm):
200
Width (mm):
40
Nominal Roller Set Bore Diameter (mm):
175
Dynamic Load Rating (kN):
173
Static Load Rating (kN):
474
INA Equivalent:
NA4832-XL
Allowable Rotational Speed (r/min):
2500
Max. Operating Temperature:
120°C/248°F
Min. Operating Temperature:
-20°C/-4°F
DescriptionThe NA4832 is a Standard Duty Open Type, Single Row Machined Needle Roller Bearing with an Inner Ring. The Inner Ring is separable from the Cage and Outer Ring, while the Outer Ring is fixed to the Cage and has an oil groove and an oil hole. Bearings with an Inner Ring are used when the shaft being used isn't heat-treated and finished by grinding. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 160X200X40mm. The INA equivalent is NA4832-XL.
Product InformationBRAND: SKU:na4832-iko AVAILABILITY:In Stock ✅ WEIGHT:3.9 kg Technical DataInside Diameter (mm):160 Outside Diameter (mm):200 Width (mm):40 Nominal Roller Set Bore Diameter (mm):175 Dynamic Load Rating (kN):173 Static Load Rating (kN):474 INA Equivalent:NA4832-XL Allowable Rotational Speed (r/min):2500 Max. Operating Temperature:120°C/248°F Min. Operating Temperature:-20°C/-4°F | ||||||||
