INA
NA4916-XL INA Machined Needle Roller Bearing - 80X110X30MM
SKU: na4916-xl-ina
Availability: In Stock ✅
BULK PRICING: Click Here to Enquire
Description
The NA4916-XL is a Standard Duty Open Type, Single Row Machined Needle Roller Bearing with an Inner Ring. The Inner Ring is separable from the Cage and Outer Ring, while the Outer Ring is fixed to the Cage and has a lubrication groove and an oil hole. Bearings with an Inner Ring are used when the shaft being used isn't heat-treated and finished by grinding. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high radial load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 80X110X30mm.
The IKO equivalent is NA4916.
| NA | 49 | 16 | XL | |
|---|---|---|---|---|
| Single Row Caged Needle Roller Bearing | Dimension Series 49 | 80mm - Bore Size | X-Life Bearing | Including Inner Ring |
Product Information
Technical Data
Inside Diameter (mm):
80
Outside Diameter (mm):
110
Width (mm):
30
Raceway Diameter Inner Ring (mm):
90
IKO Equivalent:
NA4916
Dynamic Load Rating (kN):
101
Fatigue Load Rating (kN):
31
Limiting Speed Rating (r/min):
5100
Reference Speed Rating (r/min):
2900
Static Load Rating (kN):
174
Max. Operating Temperature:
120°C/248°F
Min. Operating Temperature:
-30°C/-22°F
DescriptionThe NA4916-XL is a Standard Duty Open Type, Single Row Machined Needle Roller Bearing with an Inner Ring. The Inner Ring is separable from the Cage and Outer Ring, while the Outer Ring is fixed to the Cage and has a lubrication groove and an oil hole. Bearings with an Inner Ring are used when the shaft being used isn't heat-treated and finished by grinding. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high radial load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 80X110X30mm. The IKO equivalent is NA4916.
Product InformationBRAND: SKU:na4916-xl-ina AVAILABILITY:In Stock ✅ WEIGHT:0.819 kg Technical DataInside Diameter (mm):80 Outside Diameter (mm):110 Width (mm):30 Raceway Diameter Inner Ring (mm):90 IKO Equivalent:NA4916 Dynamic Load Rating (kN):101 Fatigue Load Rating (kN):31 Limiting Speed Rating (r/min):5100 Reference Speed Rating (r/min):2900 Static Load Rating (kN):174 Max. Operating Temperature:120°C/248°F Min. Operating Temperature:-30°C/-22°F | ||||||||||
