NKI65/25-XL INA Machined Needle Roller Bearing - 65X90X25MM
SKU: nki65/25-xl-ina
Availability: In Stock ✅
BULK PRICING: Click Here to Enquire
Description
The NKI65/25-XL is a Light Duty Open Type, Single Row Machined Needle Roller Bearing with an Inner Ring. The Inner Ring is separable from the Cage and Outer Ring, while the Outer Ring is fixed to the Cage. Bearings with an Inner Ring are used when the shaft being used isn't heat-treated and finished by grinding. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 65x90x25mm.
| NKI | 65 | /25 | XL | |
|---|---|---|---|---|
| Single Row Caged Needle Roller Bearing | 65mm Bore Size | 25mm Width | X-Life Bearing | Including Inner Ring |
Product Information
Technical Data
Inside Diameter (mm):
65
Outside Diameter (mm):
90
Width (mm):
25
Raceway Diameter Inner Ring (mm):
73
Fatigue Load Rating (kN):
17.9
Dynamic Load Rating (kN):
60
Limiting Speed Rating (r/min):
6300
Reference Speed Rating (r/min):
3900
Static Load Rating (kN):
100
Max. Operating Temperature:
120°C/248°F
Min. Operating Temperature:
-30°C/-22°F
DescriptionThe NKI65/25-XL is a Light Duty Open Type, Single Row Machined Needle Roller Bearing with an Inner Ring. The Inner Ring is separable from the Cage and Outer Ring, while the Outer Ring is fixed to the Cage. Bearings with an Inner Ring are used when the shaft being used isn't heat-treated and finished by grinding. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 65x90x25mm.
Product InformationBRAND: SKU:nki65/25-xl-ina AVAILABILITY:In Stock ✅ WEIGHT:0.467 kg Technical DataInside Diameter (mm):65 Outside Diameter (mm):90 Width (mm):25 Raceway Diameter Inner Ring (mm):73 Fatigue Load Rating (kN):17.9 Dynamic Load Rating (kN):60 Limiting Speed Rating (r/min):6300 Reference Speed Rating (r/min):3900 Static Load Rating (kN):100 Max. Operating Temperature:120°C/248°F Min. Operating Temperature:-30°C/-22°F | ||||||||||
