IKO
TR253820 IKO Machined Needle Roller Bearing - 25X38X20MM
SKU: tr253820-iko
Availability: In Stock ✅
BULK PRICING: Click Here to Enquire
Description
The TR253820 is a Heavy Duty Open Type, Single Row Machined Needle Roller Bearing with an oil groove and oil hole in the Outer Ring. This Bearing has no Inner Ring, meaning the Needle Rollers are mounted directly onto the shaft. As such, the Bearing has better running accuracy as it isn't affected by assembling an Inner Ring with the shaft. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 25x38x20mm.
| TR | 25 | 38 | 20 |
|---|---|---|---|
| Single Row Caged Needle Roller Bearing | 25mm Bore | 38mm OD | 20mm Width |
Product Information
Technical Data
Inside Diameter (mm):
25
Outside Diameter (mm):
38
Width (mm):
20
Nominal Roller Set Bore Diameter (mm):
25
Dynamic Load Rating (kN):
28.9
Static Load Rating (kN):
35
Allowable Rotational Speed (r/min):
16000
Max. Operating Temperature:
120°C/248°F
Min. Operating Temperature:
-20°C/-4°F
DescriptionThe TR253820 is a Heavy Duty Open Type, Single Row Machined Needle Roller Bearing with an oil groove and oil hole in the Outer Ring. This Bearing has no Inner Ring, meaning the Needle Rollers are mounted directly onto the shaft. As such, the Bearing has better running accuracy as it isn't affected by assembling an Inner Ring with the shaft. In caged Needle Roller Bearings like this one, the Needles are precisely guided by the Cage to achieve ideal load distribution. These Bearings are designed for high load carrying capacity in radially compact arrangements and are used in most general purpose applications. The Bearing's dimensions are 25x38x20mm.
Product InformationBRAND: SKU:tr253820-iko AVAILABILITY:In Stock ✅ WEIGHT:0.071 kg Technical DataInside Diameter (mm):25 Outside Diameter (mm):38 Width (mm):20 Nominal Roller Set Bore Diameter (mm):25 Dynamic Load Rating (kN):28.9 Static Load Rating (kN):35 Allowable Rotational Speed (r/min):16000 Max. Operating Temperature:120°C/248°F Min. Operating Temperature:-20°C/-4°F | ||||||||
