Description
Introducing the FYH UCT217 Take-Up Unit, engineered to deliver exceptional performance and reliability in various industrial applications. This meticulously crafted Take-Up Unit is designed by FYH, a renowned leader in bearing technology, ensuring unparalleled quality and durability. This robust unit comes fitted with a new, fully sealed, UC217 Bearing Insert with a 85mm inside diameter.
Key Features
High-Quality Construction
Constructed with precision using premium-grade cast iron, the FYH UCT217 boasts superior durability, capable of withstanding heavy loads and harsh operating conditions.
Efficient Take-Up Design
The take-up design allows for easy adjustment of the bearing position, facilitating optimal tensioning of belts or chains, ensuring smooth and efficient operation.
Versatile Application
Suitable for a wide range of industrial machinery and equipment, including conveyors, fans, agricultural machinery, and more, this unit offers versatility in application.
Replaceable Inserts
The Bearing Insert in the UCT217 can be easily removed from the T217 housing, allowing for future replacements as needed.Self-Aligning Ability
The convex shape of the Bearing Inserts outer ring along with the concave sphered shape inside the housing gives this UCT217 Take-Up Unit the ability to self-align, adjust for shaft deviation, and reduce abnormal load.
Product Information
Technical Data
Dynamic Load Rating (kN) :
84
Shaft Diameter (mm) :
85mm
Static Load Rating (kN) :
61.9
Bearing Insert :
UC217
Housing Length (mm) :
260mm
Housing Number :
T217
Height (H) :
198mm
A1 (Machine Slot) :
30mm
DescriptionIntroducing the FYH UCT217 Take-Up Unit, engineered to deliver exceptional performance and reliability in various industrial applications. This meticulously crafted Take-Up Unit is designed by FYH, a renowned leader in bearing technology, ensuring unparalleled quality and durability. This robust unit comes fitted with a new, fully sealed, UC217 Bearing Insert with a 85mm inside diameter. Key FeaturesHigh-Quality ConstructionConstructed with precision using premium-grade cast iron, the FYH UCT217 boasts superior durability, capable of withstanding heavy loads and harsh operating conditions. Efficient Take-Up DesignThe take-up design allows for easy adjustment of the bearing position, facilitating optimal tensioning of belts or chains, ensuring smooth and efficient operation. Versatile ApplicationSuitable for a wide range of industrial machinery and equipment, including conveyors, fans, agricultural machinery, and more, this unit offers versatility in application. Replaceable InsertsThe Bearing Insert in the UCT217 can be easily removed from the T217 housing, allowing for future replacements as needed.Self-Aligning AbilityThe convex shape of the Bearing Inserts outer ring along with the concave sphered shape inside the housing gives this UCT217 Take-Up Unit the ability to self-align, adjust for shaft deviation, and reduce abnormal load. Product InformationBRAND: SKU:uct217-fyh AVAILABILITY:In Stock ✅ WEIGHT:11 kg Technical DataDynamic Load Rating (kN) :84 Shaft Diameter (mm) :85mm Static Load Rating (kN) :61.9 Bearing Insert :UC217 Housing Length (mm) :260mm Housing Number :T217 Height (H) :198mm A1 (Machine Slot) :30mm | ||||||||
